Video amplifier with level adjustment control (RCA) 1 in 4 out

Video amplifier with level adjustment control (RCA) 1 in 4 out

Part number: ACC-VA104R

• Video / Audio Amplifier 1-in-4 Output
•  Video Input Level: 1.0V p-p
•  Audio Input Level: 2.0V p-p Max
•  Video Output Level: 2.0V p-p
•  Audio Output Level: 2.0V p-p
•  Output / Input Impedance: 75Ω
•  Dimension: 5.0"(W) x 4.0"(H) x 0.75"(D)
•  Operating Temperature: 5°C - 60°C
•  Power Input DC 12V 500mA
•  Power Consumption: 2.4 Watts
•  DC 12V 500mA Power Adaptor Included
